Key Features
-
Precision Weighing: 0.1 mg readability for analytical accuracy up to 220g
-
Internal Calibration: Maintains measurement reliability automatically
-
Rapid Stabilization: Weighing time under 5 seconds improves efficiency
-
Comprehensive Connectivity: RS232C, USB-A, USB-B, and clock for lab integration
-
Class I Accuracy: Meets the highest precision standards for laboratory use
-
OIML E2 Certified: Compatible with international standard calibration weights
-
Compact Design: Small footprint with robust construction and Ø90 mm pan
-
Temperature-Controlled Operation: Reliable performance from +18°C to +35°C
Specifications
| Specification | Details |
|---|---|
| Model | ACN220G |
| Capacity (Max) | 220 g |
| Reading Unit (d) | 0.1 mg |
| Verification Unit (e) | 1 mg |
| Calibration | Internal |
| Accuracy Class | I (Class I) |
| Interfaces | RS232C, USB-A, USB-B, Clock |
| Working Temperature | +18°C to +35°C |
| Weighing Time | Under 5 seconds |
| Dimensions (Overall) | 234 × 345 × 356 mm |
| Weighing Chamber Dimensions | 175 × 140 × 230 mm |
| Pan Size | Ø90 mm |
| Power Supply | ~230V 50Hz 6VA / 12V 1.2A |
| OIML Standard Compliance | E2 200g |
