Fully Automatic Tablet Press is one of the ideal equipment for processing granular raw materials into tablets or granules in the pharmaceutical, chemical, food, and electronic industries. It is suitable for small batch production, laboratories, hospitals, and other departments to press pharmaceutical tablets, coal catalysts, sugar tablets, calcium tablets, coffee tablets, powder metallurgy, electronic components, and various agricultural fertilizer tablets.
Technical Specification of Automatic Tablet Press
| Model | MZD-12 | MZD-20 | MZD-30 | MZD-40 | MZD-60 | MZD-100 | MZD-150 |
| Pressure range | 0.2-12.0 tons | 0.2-20.0 tons | 0.2-30.0 tons | 0.2-40.0 tons | 0-60.0 tons | 0-100.0 tons | 0-150.0 tons |
| Pressure process | Program pressurization-program pressure maintenance-timed pressure release | Normal or connected multi-stage pressurization and can display the pressure curve | |||||
| Pressure holding time | 1 s to ∞ s | ||||||
| Pressure conversion | The program automatically converts the pressure that the mold can withstand | ||||||
| LCD display | 4.3-inch LCD screen | 7-inch (IPS HD) touch screen | |||||
| Metal buttons | Silver-plated contacts, service life > 100,000 times | ||||||
| Equipment protection | Steel plate protection with plexiglass door | ||||||
| Limit switch | Automatic pressure relief when oil cylinder reaches the limit height | ||||||
| Remote control | / | (Optional) Computer for remote operation | (Optional) Computer for remote operation and print reports | ||||
| Cylinder stroke | 30mm (T) | 30mm (T) | 30mm (T) | 50mm (T) | 50mm (T) | 50mm (T) | 50mm (T) |
| Spatial dimensions (MXN) | 110x140mm | 140X160 mm | 140X160 mm | 175X180mm | 185X220mm | 185X250mm | 200X260mm |
| Dimensions (LXWXH) | 185x320x360mm | 230X390X420mm | 230X390X420mm | 280X460X550mm | 300X520X580mm | 330X580X620mm | 400X620X620mm |
| Voltage | 240W(220V/110 Can be customized) | 550W(220V/110Can be customized) | 550W(220V/110 Can be customized) | 1500W(220V/110 Can be customized) | 1500W(220V/110 Can be customized) | ||
| Weight | 50Kg | 90Kg | 95 Kg | 150Kg | 180Kg | 240Kg | 380kg |
