Digital Laser Tachometer

Digital Laser Tachometer – Non-Contact RPM Precision Tool

The Digital Laser Tachometer is a compact, high-accuracy device designed for measuring the rotational speed of various moving parts without requiring physical contact. Whether you’re working in industrial maintenance, automotive diagnostics, or machinery calibration, this non-contact RPM meter delivers reliable results every time.

Using advanced laser technology, it detects the reflection from a target surface to calculate speed, offering a measurement range typically from 2.5 to 99,999 revolutions per minute (RPM). This laser speed tester is ideal for situations where direct contact could be dangerous or inaccessible. Simply aim the device at a reflective marker on a rotating object, and the clear LCD screen displays instant, accurate RPM readings.

This handheld tachometer is built for convenience and durability. Its lightweight body fits comfortably in one hand, making it perfect for use in the field or on the factory floor. The device also includes memory recall for the last, minimum, and maximum readings—great for performance comparisons and analysis.

The tachometer’s intuitive operation, long battery life, and automatic shut-off feature make it an efficient tool for professionals and hobbyists alike. It’s widely used across industries including HVAC, motor testing, fan speed monitoring, and educational demonstrations.

For anyone needing a dependable and portable precision RPM measurement tool, this Digital Laser Tachometer offers unbeatable accuracy, versatility, and ease of use.

QUICK REVIEW:

• Test Range :- 2.5 to 99,999 RPM
• Resolution :- 0.1 RPM (2.5 to 999.9 RPM)
• Accuracy :- ±(0.05%+1 digit)
• Sampling Time :- 0.8 sec. (over 60 RPM)
• Tesst Range Select : Automatic
• Memory :- Max. Value Min. Value, Last Value
• Detecting Distance :- 50 to 250 mm/2 to 10 inch (LED)
•  50 to 500 mm/2 to 20 inch (laser)
• Time Base :- Quartz crystala
• Circuit :- Exclusive one-chip of microcomputer LSI circuit.
• Battery :- 4/1.5V AAA(Um-3)
• Power Consumption :- Approx 45.A (peration) LED
• Size :- 190x72x37 mm
• Weight :- 220g (Including Battery)
• Model :- DT-2234C
• Make :- Lutron
