The DTC-100H Dry Bath Incubator with Heated Lid is a high-precision laboratory device designed for accurate temperature control. It features a heated lid to prevent sample evaporation, digital temperature regulation, and uniform heating for reliable performance. With interchangeable heating blocks, it accommodates various sample types, making it ideal for applications like enzyme reactions, DNA amplification, and protein denaturation in biological, medical, and chemical research.
Feature of DTC-100H Dry Bath Incubator with Heated Lid
- Novel and unique appearance, simple interface operation, small size.
- Using 5-inch TFT high-definition full-touch color screen, can quickly edit the required documents, temperature curve visual display, the setting is convenient and fast, real-time accurate display temperature curve and instrument operation process status.
- Refrigeration type is based on semiconductor heating and cooling technology, and PID temperature control technology design, the rate of heating and cooling is excellent.
- Ingenious elastic hot cover structure design, adaptive to different heights of the test tube, to ensure the consistency of the experiment, to achieve the best conditions of the experiment.
- The hot cover temperature setting has two modes: independent setting mode, block temperature plus setting value.
- Built-in 10 groups of programs, each group of programs can add or delete temperature steps or cycle steps.
- Various types of blocks can be selected at need, easy to install and disassemble.
Technical Specifications
Block temp. setting range | – 10℃~100℃ |
Block temp. control range | (R.T.-25℃)~100℃ |
Temp. Max. Decrease | R.T. decreases 25℃@R.T. 26℃ |
Hot lid temp. setting range(≤105℃) | 0~105℃ / Block+(0~105℃) |
Hot lid temp. control range | R.T.+5℃~105℃ |
Time range | 1s ~99m59S / 0 is ∞ |
Max. number of steps | 10 |
Max. number of cycles | 99 |
Block temp. control accuracy | ±0.5℃ |
Hot lid temp. accuracy | ±1.0℃ |
Block temp. uniformity | ±0.5℃ |
Display accuracy | 0.1℃ |
Heating time (R.T.25℃) | Heating rate(37℃-100℃)≥7℃/min |
Cooling time | Cooling rate(100℃-37℃)≥8℃/min |
Dimension | W.185xD.280xH.160mm |
Net weight | 3.2Kgs |
