Heating Mantle (Combined Unit)


The Heating Mantle (Combined Unit) is an all-in-one solution that integrates both the heating element and temperature controller into a single compact unit. Designed for efficient and uniform heating of round-bottom flasks, it features precise control with built-in knobs or digital display, depending on the model. This plug-and-play system eliminates the need for external controllers, saving space and simplifying setup. Ideal for distillation, reflux, and general lab heating tasks, the unit is constructed with a durable, chemical-resistant body for long-lasting, safe performance.

Compare

Features

  • PU Coated Mild Steel construction
  • Heating Mantle Combined unit made of M. steel
  • ON-OFF knob for heat power control
  • Mantle knitted with glass fibre yarn
  • Provides uniform heating to flasks
  • For Round Bottomed Flasks as per DIN – 12347
  • Easy maintenance
  • Long Life
  • Also Available with metalic stand 1100.EU



Technical Specification:

Heating Mantle Body : Made of Mild Steel
Heating mantle material : Glass fibre yarn
Mantle Capacity : To hold Standard round bottom flasks upto 500ml
Valuable stirring speed  : 750 RPM
Temperature Range : Approx. 400°C
Heating Control : Electronic power regulator
Stir Control : Electric regulator
Dimension : 495x246x200
Permissible relative moisture : 80%
Permissible Ambient Temperature : 5-40°C
IP Class : 10
Temp Mantle Capacity Places Heating Mantle Material
400° C 100-500ml 3 & 6 Glass fibre yarn



Included Accessories:

  • Vertical Rod stainless steel length 542mm, ∅ 9.8mm
  • Horizontal Rod stainless steel length 972mm, ∅ 9.8mm
  • 8/5 Boss Head
  • 6/3 clamp
