The Jaw Crusher For Production is one of many crushers, mainly used in various ores, metallurgy, mining, chemical industry, building materials, refractory materials, ceramics, environmental protection, materials, biology, etc. It mainly relies on the movable jaw plate to periodically press against the fixed jaw plate to squeeze and crush the material sandwiched therein to obtain the finest 1mm material.
Features of Jaw Crusher For Production
- The powder particle size is uniform and fine and can be directly used for analysis and testing.
- Fully sealed design, no sample loss.
- Crushing jaw plates available in a variety of materials
- Air blowing dust removal design ensures clean discharge without dust pollution.
Product Specification
| Model | MT-ZY10 | MT-ZS10 | MT-ZM10 | MT-ZT10 |
| Jaw plate material | Zirconia | Corundum | Manganese steel | Tungsten carbide |
| Feed port size | 180*180mm | 180*180mm | 180*180mm | 180*180mm |
| Material feed size* | <50mm | <50mm | <50mm | <50mm |
| Final fineness* | 1-21mm | 1-21mm | 1-21mm | 1-21mm |
| Throughput* | 300-500kg/h | 300-500kg/h | 300-500kg/h | 300-500kg/h |
| Power | 1.5kw（380V） | 1.5kw（380V） | 1.5kw（380V） | 1.5kw（380V） |
| Weight | 260kg | 260kg | 260kg | 260kg |
| Dimensions | 71*83*116cm | 71*83*116cm | 71*83*116cm | 71*83*116cm |
| Crushing hardness | Corundum ≤ Mohs 5.0, Zirconia ≤ Mohs 7.5, Manganese steel ≤ Mohs 7.0, Tungsten carbide ≤ Mohs 9.0 | |||
