Key Features
• Large Capacity: Designed to process a high volume of samples simultaneously, boosting productivity in busy labs.
• Advanced Control System: Features precise temperature and vacuum controls, ensuring optimal freeze-drying conditions for various sample types.
• User-Friendly Interface: Equipped with an intuitive digital touch screen for easy programming, monitoring, and data storage of multiple freeze-drying cycles.
• Robust & Compliant Construction: Built with high-quality materials and engineered to meet GMP and FDA standards for pharmaceutical, biological, and research applications.
• Energy Efficient & Eco-Friendly: Incorporates state-of-the-art refrigeration and vacuum systems that optimize energy use while maintaining safety and environmental compliance.
Technical parameter
| Item No |
SF7009 |
SF9009 |
SF7012 |
SF9012 |
| Ice condenser capacity |
9kg |
12kg |
| Ice condenser temperature |
-70 C° |
90℃ |
-70 C° |
-90℃ |
| Cold trap volume |
15L |
20L |
| Freeze dried chamber |
High permeability organic glass/multi manifold external valve/stainless steel chamber |
| Sample shelf |
●φ260mm/485mm.Single layer area 0.055m²/0.185m².3-10 layers/optional ● Electric heating/manual capping/optional |
| Vacuum pump |
Extreme vacuum 5*10*mbar with a pumping capacity of 8m³/h optional pump of various types |
| Oil mist filter |
Standard configuration |
| Vacuum pump connection pipe |
Single forming stainless steel flexible pipe DN16 ISO-KF L-1.2m |
| Anti-corrosive treatment |
Cold trap,condensing coil/all equipped with PTFE anti-corrosion treatment as standard. Freeze-drying organic solvents |
| External valve |
1-48 ports/optiona |
| Eutectic point judgment |
Support/Optional |
| Data export analysis |
Support/Optional |
| Power |
0.9kw |
1.5kw |
1kw |
1.6KW |
| Size |
525*570*1080mm |
