MSC-MV503T Multi-view Microscope, Trinocular

The MSC-MV503T Multi-view Microscope is a trinocular microscope designed to facilitate simultaneous observation by multiple individuals. Featuring a main viewing port and additional viewing heads, it’s ideal for teaching, collaborative research, and demonstrations. The trinocular design also allows for easy connection of a camera for imaging and documentation. This microscope provides clear and magnified views, making it a valuable tool for educational institutions, research labs, and group study environments.

Compare

Ask for Price

Multi-view Microscope Feature:

Equipped with two types of view heads to meet different user needs, supporting multiple simultaneous observations.
The heads are 360° rotatable, allowing users to adjust the observation angle flexibly and improve the comfort of observation.
The advanced infinite optical system provides excellent optical performance and ensures clear and accurate observation results.
The wide field of view makes it easier for users to capture the details of the sample.
Equipped with 4X, 10X, 40X, 100X infinite plan achromatic targets to meet different magnification observation needs.
Enables precise focusing to ensure a clear observation picture.
Provides a large and stable sample support platform for precise sample movement.
Equipped with a green LED indicator with adjustable brightness to help users accurately locate the observation area.

Category: Scientific Laboratory Brand: Scitek

Model	MSC-MV503T
View Head	Siedentopf trinocular head, Inclined at 30°, 360° Ratatable, Interpupilary distance 50-75mm, Three levels of light splitting (1pc, main microscope)
View Head	Siedentopf binocular head, Inclined at 30°, 360° Ratatable, Interpupilary distance 50-75mm (2pcs, secondary microscope)
Optical System	Infinite optical system
Eyepiece	Wide field plan eyepieces WF10×/22
Objective	Infinite plan objective 4×/N.A.0.1, 10×/N.A.0.25, 40×/N.A.0.65, 100×/N.A.1.25 (Oil)
Nosepiece	Quadruple nosepiece
Condenser	N.A.1.25 abbe condenser with variable diaphragm and filter
Focusing	Coaxial coarse & fine focus adjustment, fine division 0.002mm
Stage	Double layers mechanical stage, stage size: 180x160mm, moving range 80x50mm
lllumination	Kohler lllumination, With aperture diaphragm and field optical cable, halogen lamp 12V/100W, Brightness adjustable
Pointer Module	Middle LED pointer, brightness adjustable
Shipping Size(W×D×H)(mm)	730x570x220; 350x270x540; 440x340x560
G.W. (kg)	11;9;11
