PARSTAT MC Multichannel Potentiostat – Scalable Precision for Electrochemical Research
The PARSTAT MC Multichannel Potentiostat is a state-of-the-art, modular electrochemical workstation engineered to meet the demanding requirements of advanced research. Designed by Princeton Applied Research, this system allows scientists to customize up to 20 independently controlled channels, making it an exceptional tool for high-throughput, parallel, or multi-user electrochemical testing.
Each channel operates as a fully independent potentiostat, supporting essential techniques such as cyclic voltammetry, chronoamperometry, and advanced electrochemical impedance spectroscopy (EIS). With the ability to hot-swap modules, the PARSTAT MC ensures flexibility and uninterrupted experimentation, even during ongoing tests.
The system offers a range of module options, including:
-
PMC-1000: High-sensitivity performance with ultra-low current detection down to 1.2 fA.
-
PMC-2000A: High-frequency EIS capability up to 7 MHz, ideal for corrosion studies and materials characterization.
-
PMC-BOOSTER P10A/6V: Supports high-current electrochemical testing with up to 10 A per channel and up to 30 A in parallel mode.
This modular electrochemical workstation is controlled via the powerful VersaStudio Software, which delivers an intuitive user interface for configuring experiments, collecting data, and performing real-time analysis. Researchers can seamlessly manage multi-channel studies or synchronize complex experimental protocols with ease.
Whether you’re conducting battery testing, sensor development, or fuel cell research, the PARSTAT MC delivers precision, scalability, and performance. As a multichannel potentiostat, it empowers laboratories to expand capabilities without compromising accuracy.
Highlights
- PMC Chassis supports multiple models and up to 20 channels with its unique design with data buffer, hot-swappable and user-replaceable functional blocks.
- Model PMC-1000 provides current at ±2A to ±4 nA range, 1.2 fA and expandable (±30A to ±4 pA, 122 aA)
- Model PMC-2000A provides 6-WIRE measurement for Anode/Cathode Impedance, voltage to ± 30V, and EIS to 7 MHz.
- Model PMC-200 provides 2-potentiostats per card, 24-bit resolution, a new processor and design for faster experiments.
- Model BOOSTER P10A/6V can boost current to 10A and in parallel up to 30A.
- Easy-to-use VersaStudio software included
Applications and Software
Users can select from the different groups of techniques that are available:
Energy providing charge-discharge curves (including CC-CV) for Capacity-vs-Cycle Number or Coulombic Efficiency as well as dedicated techniques such as Constant Power, Constant Resistance and Potentiostatic / Galvanostatic Intermittent Titration Technique (PITT, GITT)
Voltammetry provides fundamental electrochemical techniques such as Cyclic Voltammetry, and Chrono-techniques. The Advanced Voltammetry techniques also include Pulse Voltammetry methods.
Corrosion provides multiple corrosion analysis techniques, including the most common ASTM standards such as Linear Polarization Resistance (LPR, ASTM G59), Tafel (ASTM G5), Cyclic Polarization (ASTM G61), etc.
Impedance may be added to any system to provide Electrochemical Impedance Spectroscopy techniques
