QM-QX12L Omnidirctional Planetary Ball Mill is used for high-tech micro computer chip control. It can run alternately for positive turn and reverse turn(0-999min), and run alternately for positive turn and pause, reverse and pause, and than positive run. It is especially suitable for cooling or intermittent operation.
Technical Specification of QM-QX12L Omnidirctional Planetary Ball Mill
| Brand Name | MITR |
| Model | 360 degree rotating omnidirectionalplanetary ball mill-MITR-QMQX-12L |
| Single JarGrinding and Total Volume | 3L*4=12L（Vacuum jar selection 2L） |
| General grinding jar material selection | Metal material selection：304 stainless steel、Tungsten carbide（YG8) |
| Nonmetal material selection： ceramic / corundum / alumina, zirconia, agate | |
| high polymer material selection:Nylon, polyurethane, polytetrafluoroethylene(PTFE) | |
| General grinding ball material selection |
Stainless steel,ceramic,corundum,alumina,zirconia, agate, tungsten carbide |
| Maximum loading per jar | Raw material and grinding ball less than 1/3 of grinding jar |
| Feeding granularity | Friable material less than 10mm,others less than 3mm |
| Discharging granularity | minimum up to 0.1μm |
| Grinding Method | Dry grinding / wet grinding / high energy alloying grinding / vacuum grinding(need customized) / low temperature grinding(need customized） |
| Planetary speed (variable frequency adjustable) | MaxRevolution 0-320r/min,Rotation 0-640r/min
Planetary total speed：0-960r/min |
| 360 degree speed(variable frequency adjustable) | 1-14rpm |
| speed ratio（revolution:rotation） | 1:2 |
| Adjusting speed control method | PLC Frequency conversion control system,Touch screen control system |
| Driving style | Gear drive |
| Grinding ball ratio(the detail ratio contact customer request)The right sheet is just for reference.In fact that we are matching according to the customer requirement. | General grinding over 800 mesh(5mm;10mm;15mm) feeding material less than 3mm |
| Fine grinding 800-1500 mesh(3mm;5mm;10mm;)feeding material less than 1mm | |
| Super fine grinding over 1500 mesh(0.1~10μm)(1mm;3mm;5mm)feeding material less than 200 mesh | |
| Voltage | 380V |
| Power | 1.5KW |
| Working method | Two or four jarsworking at the same time |
| Maximum continue working time | 72h（Timing 0-9999h） |
| Programmed control | The ball grinding used for high-tech micro computer chip control. It can run alternately for positive turn and reverse turn(0-999min), and run alternately for positive turn and pause, reverse and pause, and than positive run. It is especially suitable for cooling or intermittent operation. |
| Weight | 390kg |
| Dimension | 106*96*106cm |
| Features (direct motor connection) | The only one which have the drive mode with speed reducer with motor direct drive in the market, have replaced of traditional belt drive mode. In the past, the ball mill was mainly driven by a belt, and all the gravity is on the belt. After running for a long time, the belt is easy to aging, skid, fracture and so on. There is the direct speed reducer with motor to installed into the planetary master disk in our company, its stability is more 5 times higher than that of belt. And also there is no belt replacement every 3 months during the later maintenance. It has applied for patent protection for planetary ball mill with motor direct drive. |
