Key Features
1. Widely used for laboratory, chemistry and hospital.
2. 10 kinds of acceleration and deceleration
3. More than 10 rotors for your choice
4. High speed, low noise, compact design and small vibration
5. User-friendly LCD display provides speed, time and temperature parameters. 100 Programs can be stored.
6. Brushless frequency motor which in great torque, no powder pollution, free maintenance, quick in speed up and down
7. Imbalance sensor and over speed sensor, the centrifuge body is made of high-quality steel, very safe.
TG18D Technical Parameter：
| Max. Speed |
18500rpm |
| Max. RCF |
23990×g |
| Max. Capacity |
4×600ml |
| Time Range |
0~99h99min59sec |
| RPM/RCF Convert |
Yes |
| Noise (dB) |
≤ 65 |
| Acc/Dcc |
10 Kinds |
| Speed Accuracy |
±20r/min |
| Voltage(V/Hz) |
AC 220V/110V 50HZ/60HZ |
| Size (W x D x Hmm) |
685x500x385mm |
| Net Weight(Kg) |
75kg |
| Certificates |
CE,ISO & Calibration report are available |
Matched Rotors for TG18D
| Order No. |
Rotor |
Max Speed (rpm) |
Max Volume
(ml) |
Max. RCF（×g） |
| 18D-1 |
Swing rotor |
4000 |
4×600ml(round cup) |
3530 |
| 18D-2 |
Swing rotor |
4000 |
4x600ml(square cup) |
3450 |
| 18D-3 |
Swing rotor |
4000 |
4x7x50ml |
3470 |
| 18D-4 |
Swing rotor |
4000 |
4×24×10ml |
3150 |
| 18D-5 |
|
4000 |
4×30×7/5ml |
2840 |
| 18D-6 |
Fixed Rotor |
14000 |
4×8PCR |
12070 |
| 18D-7 |
Fixed Rotor |
13000 |
6×8PCR |
16080 |
| 18D-8 |
Fixed Rotor |
14000 |
8×8PCR |
13390 |
| 18D-9 |
Fixed Rotor |
13000 |
12×8PCR |
17220 |
| 18D-10 |
Fixed Rotor |
14000 |
40×0.5ml |
19960 |
| 18D-11 |
Fixed Rotor |
18500 |
12×1.5ml |
23990 |
| 18D-12 |
Fixed Rotor |
15000 |
24×1.5ml |
20600 |
| 18D-13 |
Fixed Rotor |
13500 |
30×1.5ml |
19340 |
| 18D-14 |
Fixed Rotor |
11000 |
48×1.5ml |
12840 |
| 18D-15 |
Fixed Rotor |
15000 |
16×5ml |
19350 |
| 18D-16 |
Fixed Rotor |
14000 |
6×10ml |
16460 |
| 18D-17 |
Fixed Rotor |
13000 |
12×10ml |
17030 |
| 18D-18 |
Fixed Rotor |
11000 |
16×10ml |
13950 |
| 18D-19 |
Fixed Rotor |
11000 |
8×15ml |
12730 |
| 18D-20 |
Fixed Rotor |
9000 |
12×15ml |
9590 |
| 18D-21 |
Fixed Rotor |
5000 |
24×15ml |
3500 |
| 18D-22 |
Fixed Rotor |
5000 |
30×15ml |
3830 |
| 18D-23 |
Fixed Rotor |
12000 |
6×30ml |
14000 |
| 18D-24 |
Fixed Rotor |
12000 |
6×50ml(conical) |
16050 |
| 18D-25 |
Fixed Rotor |
12000 |
6×50ml(round) |
15960 |
| 18D-26 |
Fixed Rotor |
11000 |
4×85ml |
13560 |
| 18D-27 |
Fixed Rotor |
10000 |
4×100ml |
10310 |
| 18D-28 |
Fixed Rotor |
8000 |
6×100ml |
7280 |
| 18D-29 |
Fixed Rotor |
4000 |
12×100ml |
2970 |
| 18D-30 |
Fixed Rotor |
12000 |
24 capillaries |
15800 |
| 18D-31 |
Swing Rotor |
15000 |
4×5ml |
19920 |
| 18D-32 |
Vertical rotor |
16000 |
16×5ml |
16450 |
| 18D-33 |
Vertical rotor |
14000 |
8×30ml |
19750 |
| 18D-34 |
Microplate rotor |
4000 |
2x4x96 well |
3210 |
