The Tri-Gas Controller is an advanced gas regulation system designed for research and laboratory applications requiring precise environmental control. Capable of delivering a user-defined mixture of oxygen (O₂), carbon dioxide (CO₂), and nitrogen (N₂), this controller is ideal for hypoxic and anoxic studies, cell culture incubation, and customized gas supply to glove boxes or enclosed chambers.
Equipped with real-time digital monitoring and adjustment, the Tri-Gas Controller allows researchers to fine-tune gas concentrations accurately. Its programmable interface supports automated control of gas levels for long-duration experiments, ensuring stable and repeatable conditions. It features compatibility with most laboratory chambers and incubators, making it a versatile addition to any biomedical or life sciences lab.
The controller includes built-in safety alarms for gas pressure anomalies, easy calibration procedures, and durable components for long-term reliability. Whether you’re working in cancer biology, stem cell research, or microbiology, the Tri-Gas Controller provides the precision and consistency essential for sensitive experiments.
Key Features
-
Three-Gas Compatibility: Precisely mixes and regulates O₂, CO₂, and N₂
-
Real-Time Monitoring: Live digital readout for gas concentration levels
-
Adjustable O₂/CO₂ Ranges: Custom setpoints for hypoxic, normoxic, or hyperoxic conditions
-
Programmable Control: Set and maintain gas levels over timed intervals
-
Sensor Calibration System: Quick and easy in-house calibration options
-
Integrated Safety Alarms: Alerts for low cylinder pressure or concentration deviation
-
Compact & Modular Design: Easily connects to incubators, glove boxes, and chambers
-
Touchscreen Interface (optional): For intuitive user control
-
Sturdy Construction: Built with lab-grade materials for durability
-
Low Maintenance: Designed for minimal upkeep with long-life sensors
Specifications
| Parameter | Specification |
|---|---|
| Gas Inputs | O₂, CO₂, N₂ (standard gas cylinders) |
| O₂ Control Range | 0.1% – 21% (adjustable) |
| CO₂ Control Range | 0.1% – 20% (adjustable) |
| N₂ Control | Balancing gas to regulate O₂ & CO₂ levels |
| Control Accuracy | ±0.1% for O₂ and CO₂ |
| Flow Rate | 0.1 to 10 L/min (depending on model) |
| Display | Digital or optional touchscreen |
| Sensor Type | Electrochemical (O₂), Infrared (CO₂) |
| Calibration | Manual or auto-calibration |
| Alarms | Gas supply is low, out-of-range detection |
| Communication Ports | USB or RS-232 (optional for data logging) |
| Power Supply | 110–240V AC, 50/60Hz |
| Dimensions | 300 × 200 × 150 mm |
| Weight | 8 kg |
