| General Specification |
Details |
| MODEL |
FTSG-2000 |
| Inner Size (W×D×H)mm |
1,700 x 800 x 1,500 |
| Outer Size (W×D×H)mm |
1,900 x 1,400 x 2,260 |
| Convection Method |
Descending airflow method |
| Capacity |
2,040 Liter |
| Temperature |
Adjustment Range: 10°C to 50°C (when turned off), 20°C to 50°C (when external lights are turned on), 25°C~50°C (when external and internal LED illumination is on) <br> Control Method: Heater control: PID control, Refrigeration control: ON-OFF control <br> Adjustment Precision: ±1°C (when turned off), ±2°C (when external lighting is turned on), ±4°C (when external and internal LED illumination lights) <br> Sensor: PT-100 Ω |
| Humidity |
Adjustment Range: 50% To 90% <br> Control Method: Heater control: PID control, Refrigeration control: ON-OFF control <br> Adjustment Precision: About ±10%~20% <br> Sensor: Electronic device (electronic sensor) |
| Temperature and Humidity Controller |
Touch screen TH-500 |
| Illuminance |
Adjustment Range: 0 to about 2,500 Lx 6-step adjustment, LED cycle 4-step adjustment <br> Control Method: LED control with backlight: timer control, Cycle control <br> Fluorescent Lamp: White fluorescent light 32W = 24 EA <br> LED Lighting: 310 type water cultivation mixed type 600mm waterproof type = 32 EA <br> Regulator: 24 hour 15 minute interval timer, Cycling digital timer = 4 EA |
| Environment |
10°C-30°C |
| Material |
Inside: Stainless steel <br> Out: Steel plate with powder coating <br> Glass Door: Left and right side reinforced mast glass 12 T = 2 sheets, Front reinforced glass 5 T = 2 sheets |
| Pipe |
Rating: Automatic water supply valve or free, With carbon filter unit <br> Drainage: Automatic electric valve 25 A 15 pie = 8 EA <br> Drain: PVC pipe line installation |
| Shelf |
Bat: Manufactured to be able to use the tabletop pedestal, Stainless steel = 8 EA <br> Pedestal: Stainless steel base plate = 8 EA |
| Refrigerator Capacity |
1/2 HP |
| Freezer. Refrigerant |
Air cooling 300 W, R134A |
| Safety Device |
Over/Under temp, Protor, Level monitor, Power breaker, Hi-low lime S/W |
| Power |
AC 220 V, 25 A, 50/60 Hz |
